Features:

●Based on T5L2, running DGUS II system, commercial grade;7.0-inch, 800*1280 Pixels resolution, 16.7M Colors, IPS-TFT-LCD, wide viewing angle; ●Capacitive touch screen  ●UART2: ON=TTL/CMOS; OFF=RS232 UART4: ON=TTL/CMOS; OFF=RS232;8Pin_2.0mm socket for power supply and serial communication; ●Two Download ways:via SD card or on-line serial port; ●With IPS View Angle:85/85/85/85(L/R/U/D);

User interface    8Pin_2.0mm socket for power supply and serial communication. Download rate(typical value): 14KByte/s Flash    16 MBytes NOR Flash, for fonts, pictures and audio files. Rewrite cycle: over 100,000 times Expand Flash    Expandable to 64Mbytes NOR Flash or 48Mbytes NOR Flash+512Mbytes NAND Flash Buzzer    3V passive buzzer. Power: <1W RTC    Button cell for power supply. Accuracy: ±20ppm @25℃ SD card interface    FAT32. Download files by SD interface can be displayed in statistics. Download rate: 4Mb/s

BRIGHTNESS  300 NIT

Operating Voltage    6~36V, typical value of 12V Operating Current    200mA    VCC=12V, max backlight 80mA    VCC=12V, backlight off

Recommended power supply: 12V 1A DC
