Features:
● Based on T5L0 ASIC 7.0 Inch,800xRGBx480,262K Colors, TN screen;
● Touch mode: Capacitive
● TTL and RS232 optional
● Support SD card and DGUS tool on-line download ;
● V7.6 DGUS tool for GUI design, Zero code needed;
● Dual Development System: DGUSⅡ/TA(Instruction set);
● Normal View Angle: 70/70/50/70(L/R/U/D);
● Single 8051 chip with dual-core, GUI and Opened OS core. OS core can be programmed by DWIN OS language or Keil C to instead of customer ’MCU .

User Interface
8PIN 2.0
Download rate(typical value): 12KByte/s
UART2: N81  ON=TTL/CMOS; OFF=RS232(RS232 as default)
UART4: N81/E81/O81/N82 4 modes ON=TTL/CMOS; OFF=RS232(Support after OS configuration)
Accessories:HDL65011 cable,SD card

BRIGHTNESS  : 270 NIT
