The TCS34725 device provides a digital return of red, green, blue (RGB), and clear light sensing values. An IR blocking filter, integrated on-chip and localized to the color sensing photodiodes, minimizes the IR spectral component of the incoming light and allows color measurements to be made accurately.

The high sensitivity, wide dynamic range, and IR blocking filter make the TCS34725 an ideal color sensor solution for use under varying lighting conditions and through attenuating materials.




1. Red, Green, Blue (RGB), and White Light Sensing with IR Blocking Filter

2. Programmable Analog Gain and Integration Time

3. 3,800,000:1 Dynamic Range

4. Very High Sensitivity . Ideally Suited for Operation Behind Dark Glass

5. Maskable Interrupt

6. Programmable Upper and Lower Thresholds with Persistence Filter

7. Power Management

8. Low Power ? 2.5-uA Sleep State

9. 65-uA Wait State with Programmable Wait State Time from 2.4 ms to > 7 Seconds

10. I2C Fast Mode Compatible Interface

11. Data Rates up to 400 kbit/s

12. Input Voltage Levels Compatible with VDD or 1.8 V Bus

13. Register Set and Pin Compatible with the TCS3x71 Series

14. Small 2 mm*2.4 mm Dual Flat No-Lead (FN)



COLOR Sensor Module 34725
