TP interface    Capacitive touch: 6Pin_0.5mm  User interface    10Pin_1.0mm latching socket for power supply and serial communication. Download rate(typical value): 12KByte/s Flash    16 MBytes NOR Flash, for fonts, pictures and audio files. Rewrite cycle: over 100,000 times Buzzer    3V passive buzzer. Power: <1W SD card interface    FAT32. Download files by SD interface can be displayed in statistics. Download rate: 4Mb/s PGT05 interface    When product crashes by accident, you can use PGT05 to update DGUS kernel and make the product return to normal

Display Parameters

LCD Type    TN, TFT LCD Viewing Angle    Normal viewing angle, 70°/70°/50°/70° (L/R/U/D) Resolution    240×320 pixels (0°/90°/180°/270°) Color    18-bit 6R6G6B Brightness: 250nit

Touch Parameters     Type    CTP (Capacitive touch panel) Structure    G+G structure with surface cover of tempered glass Touch Mode    Single point touch, support continuous sliding touch Surface Hardness    6H Light Transmittance    Over 90% Life    Over 1,000,000 times touch

Serial Interface Parameters     Mode    UART2: TTL/CMOS; UART4: TTL/CMOS; (Only available after OS configuration) Baud Rate    3150~3225600bps, typical value of 115200bps Data Format    UART2: N81 UART4: N81/E81/O81/N82 , 4 modes (OS configuration) Interface Cable    10Pin_1.0mm

Electrical specifications

Rated Power    <5W Operating Voltage    4.5~5.5V, typical value of 5V Operating Current    120mA    VCC=5V, max backlight 60mA    VCC=5V, backlight off Recommended power supply: 5V 1A DC
